Number of detectors : 1/2/4
Detector type: GeX
Detector size: 3 mm
Wavelength range (nm) : 800 to 1660
Power range (dBm) (typical) : 22 to –53 (22 to –60)
Uncertainty : ±(5% + 5 nW)
Uniformity (dB) : N/A
Polarization‑dependent responsivity (dB) : ±0.015 typical
Linearity : ±0.015 dB (5 dBm to –37 dBm)
Wavelength resolution (nm) : 0.01
Stabilization time (ms) (typical) : 5
Sampling rate (sample/s/channel): Up to 5208
Trigger input voltage (Vdc): 0-5 (TTL - type)
Analog output voltage (Vdc) (typical): 0-5
Fiber type (µm) : 5/125 to 62.5/125
