Models :
+ Channels: See channel grid in the ordering information table below
+ Grid wavelength of the first channel (nm) : 1270
+ Grid wavelength of the last channel (nm): 1650
Wavelength:
+ Channel center : Wavelength grid ±3 nm
+ Tuning range (nm): 1.6 (1.8 typical)
+ Accuracy (nm) : ±0.03
+ Stability over 1 hour (nm) : ±0.005
+ Stability over 24 hours (nm) : ±0.005 (typical)
Power:
+ Maximum : 10 mW (for channels from 1270 nm to 1570 nm); 8 mW (for channels from 1590 nm to 1650 nm)
+ Stability over 1 hour (dB) : ±0.01
+ Stability over 24 hours (dB) : ±0.01 (typical)
+ Optical isolation (dB) : > 30
+ RIN (Relative intensity noise) (dB/Hz): < –140
Spectrum:
+ Laser linewidth (MHz) : < 10
+ SMSR (dB) : > 30 (40 typical)
Modulations:
+ TTL (internal and external): 1 Hz to 890 kHz
+ Analog (external/front panel): 150 Hz to 150 MHz
+ SBS suppression (internal) :
Waveform: Sine:
Frequency range (kHz): 10 to 100
Modulation depth (%): 0 to 15
Interfaces on module front panel:
+ Enable key with status LED : Power up laser
+Optical fiber : SMF
+Optical connector : FC/APC narrow key
+Fiber alignment to connector key: n/a
+Polarization extinction ratio (PER) : n/a
+Electrical connector (analog modulation) : Coaxial SMB - 50 Ω
Others:
+Laser safety : Class 1 M
+Dimensions (W x H x D): 35 mm x 128 mm x 230 mm (13/8 in x 5 in x 9 in)
+Weight: 1.1 kg (2.43 lb)
