Output voltage: up to 270 VAC / up to 300 VDC
Output voltage (motor/coil): independently configurable
Current: max. 40 A
Frequency: DC, 50 Hz, 60 Hz
Measurement voltage: 0...300 VAC/DC
Measurement current: 0...100 AAC/DC
Measuring range: 0.5...1500 Ω
Power supply: Rated voltage 100...240 VAC, 47...63 Hz, current max. 20 A
Connections: 1 × Motor, 1 × I-coil, 2 × O-coil, all connection points on front panel, 4 mm safety sockets
Housing: Hard-top case
Dimensions (W × H × D): 505 × 257 × 409 mm
Weight: 19.7 kg
Screen: High-resolution, resistive 5" touchscreen
Operation: Touch screen, jog wheel, three function keys, 4 enable keys
Display elements: 4 status LEDs
Interfaces: RJ45, USB-B
