Test Frequencies
• 50, 100, 200, 400, 800 Hz
Test Value Static / Reference Value Static
• 0.01-10000 ±1% (Dimensionless calculated value)
Stator Test Dynamic
• Repeatability ±1% (of measured data and calculated deviations)
Rotor Test Dynamic
• Repeatability ±2% (of measured data and calculated deviations)
Resistance
• 0.01-999 Ω measurement range
• 0.01-99.9 Ω ±1%, Max Resolution: 0.01 mΩ
• 100 Ω-500 Ω ±1.5%, displayed as whole numbers
• 501 Ω-999 Ω ±2.5%, displayed as whole numbers
• Relative Accuracy “Phase to Phase” ± 0.1%
• True 4-wire Kelvin measurement (Compensation for thermoelectric
offset voltages)
Impedance
• 0.1-999 ±2%, Max Resolution: 0.01
• Relative Accuracy “Phase to Phase” ± 0.2%
Inductance
• 1-999mH measurement range
• 1-200mH ±2%, all other values ±3%
• Relative Accuracy “Phase to Phase” ± 0.2%
Phase Angle
• 1-90° ±1°, Max Resolution: 0.1°
• Relative Accuracy “Phase to Phase” ± 0.1°
I/F (current/frequency)
• -50%~+99% ± 1%, Max Resolution: 0.1 %
• Relative Accuracy “Phase to Phase” ± 0.1%
Dissipation Factor - DF (frame – stator)
• 1-100% measurement range (expressed as a percentage)
• 1-10% ±0.75% (C = 10-1000 nF) ±1.0% (all other values of C within
range 2-2000 nF)
• 10-30% ±1.0% (This specification is based on battery operation and
USB not connected to PC)
Capacitance (frame – stator)
• 2-2000 nF measurement range; 10-2000 nF ±5% (This
specification is based on battery operation and USB not connected to PC)
Insulation Resistance
• 0-999 MΩ @500V or 1000V
• 1-100 MΩ ±3%, all other values ±5%
Keyboard
• Alphanumeric, sealed tactile switches with backlight overlay
Accessories Included
• 3x Test Leads with heavy-duty custom Kelvin Clips and
push-pull connectors
• 1x Test Lead with 4mm safety plug and MC “Dolphin” clip
• Charging adapter, Universal input type 100-240VAC, output
9VDC @ 1.7A
• MCA Basic™ Software (Windows 7, 8.1 & 10, 64 bit)
• Available in English, Spanish, Chinese and Portuguese
• 1x USB cable 1m
• Durable and rugged hard case with pre-cut foam liner
• User Manual on CD
