Oscillation frequency range: 0.1mHz to 2MHz
Output waveform: Sine, triangle (variable symmetry), square (variable duty factor), arbitrary (ARB), DC
Vertical resolution of waveform: 12 bits
Waveform and frequency:
+ sine, square (duty 50%): 0.1mHz to 2MHz;
+ Triangle, square (other than duty 50%):0.1mHz to 50kHz
+ ARB: 0.1mHz to 50kHz
Frequency setting resolution: 0.1mHz
Frequency accuracy: ±25ppm
Triangle wave variable symmetry: Setting range: 0% to 100%, Resolution of settings: 0.1%
Square wave variable duty range: Setting range: 0% to 100%, Resolution of settings: 0.1%
Arbitrary waveform size and number: 4K words, 4 waves
Max. output voltage: 10Vp-p/open
Output voltage resolution: 0.001Vp-p
DC offset: ±5.000V/open, resolution 0.001V
Output impedance: 50Ω, unbalanced
Oscillation mode: Continuous, burst, gate, trigger
Other functions: Load function(sets and displays actual output voltage when load is open or 50Ω.), Output on/off function, Setting memory (save/call 20 sets of setting items), Battery backup, Initializing function, input/output ground
Arbitrary waveform editor: Standard equipped
Interface: USB interface, USBTMC
Power requirements: AC 90V to 250V
Power consumption: 20VA or less
Dimensions (mm): 216(W)×132.2(H)×93.5(D)
Weight: Approx. 1.2kg
