OMEGA D6100 Analog to Modbus Serial Interface Modules (Voltage, ±0.025V, ±0.05V, ±0.1V, ±1V, ±5V, ±10V, RS485)

Width: 152 mm

Height: 102 mm

Length: 38 mm

Memory: EEPROM

Baud Rate: 9600 to 115200

Materials: ABS

Input Type: Voltage

Mounting Note: 165 mm on center

Output Signal: None

Sampling Rate: 25 Hz (25 updates/second)

Data Interface: RS485

Digital Filter: Programmable

Digital Output: 5 mA minimum, 10 mA maximum

Supply Voltage: 10 to 30 Vdc

Analog I/O Note: Analog Input Note: Voltage: Number of Channels: 7 differential voltage inputs, Ranges: ±0.025V, ±0.05V, ±0.1V, ±1V, ±5V, ±10V, Resolution ADC: 16-bit ADC, 25/20 conversionsper second, Accuracy: ±0.05% of FS maximum, Span Tempco: ±50ppm/°C maximum, Input Burnout Protection: To 250 Vac, Input impedance: 20 MΩ min, Power Requirements: Serial = 1.4W

Conversion Rate: 25/20 conversions/sec

Impedance Input: 20 MΩ min

Pull-up Resistor: 10 kΩ

Relative Humidity: 0 to 95% RH non-condensing

Supply Power Note: Power Requirements: Serial = 1.4 W

Supply Power Type: DC

Common Mode Voltage: Input to Output at 115 Vrms, 60 Hz: 500 Vrms

Data Interface Note: Modbus RTU protocol;Configuration Method: Modbus

Output Settling Time: 0.1% FS: 1 ms

Electrical Connection: Screw Terminal

Transmission Distance: 1219 m

Temperature Coefficient: ±50 ppm/°C

Storage Temperature, Max: 85 °C

Storage Temperature, Min: -25 °C

Number of Channels, Input: Analog: 7 DIFF

Voltage Measurement Range: ±0.025V, ±0.05V, ±0.1V, ±1V, ±5V, ±10V

Number of Channels, Output: None

Operating Temperature, Max: 70 °C

Operating Temperature, Min: -25 °C
