Calibrated Wavelength(1): 850,1300,1310,1490,1550,1625nm
Power Range (dBm)(2): -50 ~ +27
Fiber Type: Singlemode/Multimode fibers
Detector Type: InGaAs
Accuracy: ±5% ±1nW (±0.5dB@850nm)
Resolution (dB): 0.01
MOD Identification: 270, 1K, 2K Hz
Auto Wavelength Identification : Yes (With SLS-50)
Display Unit: W/mW/µW/nW/pW/dBm/dB(REF)
Data Storage: 1000 records
Connectivity: USB
Connector(3): FC (Interchangeable SC/ST)
Power Supply: Lithium Battery/ AC Adapter
Battery Life: Continuous operation: 70 hours
Power Saving: Auto-off after 5 minutes idle
Operating Temperature: 0ºC ~ 50ºC (32 ~ 122 F)
Storage Temperature: -20ºC ~ 70ºC (-4 ~ 158 F )
Relative Humidity: 0 ~ 95% (Non-condensing)
Weight: 315g (0.69 lbs)
Dimensions (H × W × T): 177×80×44mm (6.97×3.15×1.73 inch)
Ordering Information:
Standard Package Includes::
Instrument, Lithium battery, AC adapter, USB cable, OPM data analysis software CD, Soft carrying case, Warranty card, CE certificate, Certificate of calibration,:
