Shutdown: No Shutdown
Gain Error: 0.55 %
Input Type: Single Ended
Resolution: 16 bit
Output Type: Voltage
Architecture: Sigma-Delta
Sampling Rate: 12 kS/s
Settling Time: 800 us
Interface Type: SPI
Mounting Style: SMD/SMT
Reference Type: External, Internal
Reference Voltage: 1.2 V
Number of Channels: 1 Channel
Number of Converters: 1 Converter
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 3 V
Analog Supply Voltage: 3 V to 3.6 V
Digital Supply Voltage: 3 V to 3.6 V
Pd - Power Dissipation: 15 mW
INL - Integral Nonlinearity: 2.5 LSB
SNR - Signal to Noise Ratio: 96 dB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
DNL - Differential Nonlinearity: 0.3 LSB
THD - Total Harmonic Distortion: - 89.5 dBc
SFDR - Spurious Free Dynamic Range: 89.5 dBc
