Shutdown: No Shutdown
Gain Error: 0.3 %
Input Type: Differential
Resolution: 14 bit
Output Type: CMOS
Architecture: Pipeline
Sampling Rate: 20 MS/s
Mounting Style: SMD/SMT
Reference Type: External, Internal
Development Kit: EVAL-RHF1401V2
Number of Channels: 1 Channel
Number of Converters: 1 Converter
Supply Voltage - Max: 2.7 V
Supply Voltage - Min: 2.3 V
Analog Supply Voltage: 2.3 V to 2.7 V
Digital Supply Voltage: 2.3 V to 2.7 V
Pd - Power Dissipation: 85 mW
FPBW - Full Power Bandwidth: 70 MHz
INL - Integral Nonlinearity: 1.7 LSB
SNR - Signal to Noise Ratio: 70 dB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
DNL - Differential Nonlinearity: 0.4 LSB
ENOB - Effective Number of Bits: 11.5 bit
THD - Total Harmonic Distortion: 86 dB
SFDR - Spurious Free Dynamic Range: 91 dBFS
SINAD - Signal to Noise and Distortion Ratio: 70 dB
