Fall Time: 15 ns
Rise Time: 9 ns
Technology: Si
Unit Weight: 2.240 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 29 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 30 W
Vgs - Gate-Source Voltage: - 25 V, + 25 V
Typical Turn-On Delay Time: 14 ns
Typical Turn-Off Delay Time: 60 ns
Id - Continuous Drain Current: 18 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 168 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 3 V
