Shutdown: No Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Unit Weight: 23.710 mg
Amplifier Type: Precision
Mounting Style: SMD/SMT
SR - Slew Rate: 3 V/us
THD plus Noise: 0.0003 %
Voltage Gain dB: 125 dB
Number of Channels: 2 Channel
Supply Voltage - Max: 36 V
Supply Voltage - Min: 2.7 V
Ib - Input Bias Current: 900 nA
Operating Supply Current: 1.8 mA
Ios - Input Offset Current: 10 nA
Output Current per Channel: 50 mA
Vos - Input Offset Voltage: 300 uV
GBP - Gain Bandwidth Product: 6 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 0.15 pA/sqrt Hz
en - Input Voltage Noise Density: 12 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 115 dB
PSRR - Power Supply Rejection Ratio: 125 dB
