Viavi OLP-38 Optical Power Meter (780~1650 nm, -50~26 dBm)

Detector type: Filtered InGaAs

Optical interface/connectors: Universal 2.5 mm/1.25 mm1

Wavelength range: 780 to 1650 nm

Wavelength settings: 780 to 1650 nm, step size 1 nm

Programmable wavelengths: 5 presets (customized)

Calibrated wavelengths: 850, 980, 1310, 1490, 1550, 1625 nm

Power range: –50 to +26 dBm

Display range: –50 to +26 dBm

Max. input power: +27 dBm

Measurement units: dB/dBm/W

Intrinsic uncertainty: ±0.2 dB (±5%)

Linearity: ±0.06 dB (–32 to +20 dBm)

Tone detection: 270 Hz, 1 kHz, 2 kHz

Auto λ mode: Yes

Multi λ mode: TwinTest/serial TripleTest

Power Supply

Dry batteries: 2x Mignon (AA) 1.5 V

Rechargeable batteries: 2x Mignon (AA) NiMH 1.2 V

AC operation Via micro USB and SNT-505

Dimensions (H x W x D): 30 x 80 x 150 mm (1.2 x 3.1 x 5.9 in)

Weight: 200 g (0.45 lb)
