Bandwidth (-3dB): 100MHz
Attenuation: 1:50/500
DC Gain Accuracy: ±2%
Offset zero (Scope gain=1X): ±10 mV
Between Inputs: 20Mohm, 1pF
Each input to Gnd: 10Mohm, 2pF
Rise time (small signal，10-90%，20-30°C): ≦3.7ns
Input voltage Diff. Vin (DC+ pk AC): 500X: ±3500V; 50X: ±350V
Input voltage Comm. Vin: ±3500V
Input voltage Max. Vin to Earth:
CAT I 2300V
CAT III 1000V
Impulse withstand: 6000V
CMRR (typical):
60Hz: > 80dB
100kHz: > 60dB
3MHz: > 40dB
10MHz: > 35dB
Power by: USB (5V, < 250mA)
Length of BNC / USB-cable: 90cm
Length of Lead-cable: 24cm
