ELECTRICAL MEASURE SPECIFICATIONS
Voltage DC: 0 to 30 V/ 1 mV/0.01%RD + 2mV
Current DC: 0 to 24 mA/ 1 µA/ 0.01%RD + 2µA
Switch test:
Input resistance more than 500 MΩ
Trigger level: low level <0.3V; high level: >2V
General Specifications
Voltage limit : 30V between terminals or between terminals and ground
Measurement Functions : Auto step, auto ramp, span step
Display VA LCD display : 2.04 x 2.04 in (52 x 52 mm)
Loop power : 24V
Over-voltage protection : 30V DC (240V AC)
Overload current protection : 33mA DC
Storage temperature : -20°C to 70°C
Working Environment : -10 to 50°C, 95%RH
Working Altitude : <3,000 m
Vibration/shock : Random 2G 5 to 500Hz, 1 meter drop
Power : One 9V alkaline battery (ANSI/NEDA 1604A or IEC)
DC9V optional adapter available
Battery life (typical) : Output mode : 18 hours (12 mA/500Ω)
Measure mode : 50 hours
Size (LxWxH) : 163 x 83 x 41 mm
Weight : 350 g
Calibration Certification : NIST-traceable certificate of calibration with data
Compliance Certification : ADT209 : CSA, CE, DNV
ADT210 : CSA, CE, DNV
Accessories included
9812 110V/220V external power adapter (DC 9V)
Test lead set 1 set
Alligator clips 2 pcs
User manual 1 pc
9V Alkaline battery 1 pc
