Amphenol Advanced Sensors NPH-8-700GH Board Mount Pressure Sensors 700 kPa Hybrid Gauge
Manufacturer: Amphenol Advanced Sensors Model: NPH-8-700GH - Contact
Accuracy: 0.2 %
Port Size: 3/16 in
Port Type: Single Axial Barbless
Output Type: Analog
Unit Weight: 5 g
Pressure Type: Gauge
Mounting Style: Through Hole
Output Voltage: 100 mV
Operating Pressure: 700 kPa
Supply Voltage - Max: 150 mV
Supply Voltage - Min: 50 mV
Operating Supply Current: 1.5 mA
Operating Supply Voltage: 50 mV to 150 mV
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
