- Wavelength: 0.85 μm
- Resolution: 640 x 480
- Acquisition Speed: 60 fps (60 Hz)
- Measurement Range: 600 ~ 1800°C (1112 ~ 3272°F)
- Ambient Environment: Up to 60°C (140°F)
- Camera Weight: ≈10.43 kg (23 lb)
Lens:
- Field of View: Wide 75°
- Focus: Manual
- Diameter: 42 mm (1.65")
- Lens Type: 61cm (24")
- Air cooled
Facility Connection Requirements:
- Power: 110 ~ 240 VAC, two 15 amp lines to support six cameras
- Air Supply:
15 cfm @ 100 psi @ the camera
20 cfm @ 20 psi for the lens
Networking:
- Number of Cameras: Up to 20 with a single controller (at 1 fps)
- Camera Connection: 1000 Base T Ethernet
- Field Switch Cabinet: NEMA 4 / IP65 enclosure with ethernet switch
