- Output Power: 3kW at max output voltage and current
- Output Voltage: 100 ~ 300V
- Output Current: 10 ~ 30 A depending on output voltage
- Input Voltage: 185 ~ 255 VAC 47 ~ 63 Hz single phase plus protective earth, operation below 185 VAC is possible with power derating down to 1500 W at 85 VAC
- Input Current: Not exceeding 19 ARMS. Harmonics are controlled with active power factor correction.
- Specification Range: Specifications apply above 5% of rated output voltage. The output can be controlled down to < 0.25% of ratedoutput voltage.
- Output Ripple: Voltage mode: < 0.1% peak to peak of rated output voltage +50 mV peak to peak
- Current Mode: < 0.2% peak to peak of rated output current +50 mA peak to peak
- Line Regulation: < 0.05% deviation in output voltage set point for a 10% change in supply line voltage
- Load Regulation:
Current mode: < 0.1% deviation in output current set point for a 0 to 100% change in output voltage
Voltage mode: < 0.1% deviation in output voltage set point for a 0 to 100% change in load current
- Transient Response: Response for a 10% ~ 90% or 90% ~ 10% step change in load. Overshoot/undershoot < 2% of rated output.
Recovery to within 0.1% of rated output < 10 ms.
- Temperature Coefficient: 100 ppm per °C
- Drift: < 0.5% per 8 h after 1 h warmup
- Operating Temperature: 0 ~ 40°C (32 ~ 104°F) ambient and air intake
- Storage Temperature: -20 ~ +85°C (-4°F ~ 185°F)
- Humidity: 80% max relative humidity up to 31ºC, decreasing linearly to 50% at 40°C
- Altitude: Sea level to 2000 m (6500')
- Usage: Indoor use only
- Dimensions (W x D x H): 19" rack mounting: 483 mm (19") x 88 mm (3.46") x 494 mm (19.4")
- Weight: 15 kg (33 lb)
- Interface:
Analog
Digital remote control; control is via a 25-way female D-type connector
