Accuracy: ≤± 0.02 %
Linearity Error: ≤± 0.02 %
Internal Division: 24 bit
Strain Gauge Input: ± 2 mV/V (max ± 2.5 mV/V)
Resolution: ± 20.000 div
Power Supply For Transducers: 5 Vdc
Type Of Connection: 4 wires
Transducer Resistance: da 100 Ω a 2000 Ω
Transducer That Can Be Connected In Parallel: 4 of 350 Ω or 8 of 700 Ω
Voltage Input Amplified Transducer: ± 10 V / ± 5 V
Resolution: ± 20.000 div
Power Supply For Transducers: 18 Vdc (± 1 Vdc)
Current Input Amplified Transducer: 0-20 mA ; 4-20 mA
Resolution: +20.000 div ; +20.000 div
Power Supply For Transducers: 18 Vdc (± 1 Vdc)
Input For Potentiometers: R min. 1 kΩ
Power Supply: 5 Vdc
7 Segment Display Color: RED
Number Of Digit: 5
Character Height: 14 mm
Sensor Calibration: POSITIVE AND NEGATIVE range
Type Of Digital Calibration: Full Scale
Zero Function: 100% (allowed on all measurement range)
Zero Lock Function (Loc): YES
Peak Function: POSITIVE AND NEGATIVE
Programmable Resolution: 1 … 100
Programmable Digital Filter: 0 … 5
Point Position Programmable: 0 … 5
Programmable Acquistion Frequency: From 2.5 to 1200 samples for second
Programmable Set Point: 2
Digital Input With Programmable Function: 1
Relays Output With Exchange Contacts: 2
Max Voltage To The Contacts: 24 Vdc
Max Current: 500 mA
Max Power: 12 W
Nominal Temperature Range: 0... +50 °C
Max Temperature Range: 0... +50 °C
Storage Temperature Range: -20... +70 °C
Effects On A 10°C Temp. Variation On Zero: <± 0.005 %
Effects On A 10°C Temp. Variation On Full Scale: <± 0.005 %
External Power Supply: 230 Vac ± 10 %
Frequency: 50/60 Hz
External Protection Fuse: 250 mA / 250 V
Max Power: 10 VA
Panel Container: DIN 43700
Container Material: NORYL UL94 V-O
Material Front And Rear Panel: UL94 V-2
Protection Class (En 60529): IP40 (only front panel)
Environmental Pollution Grade: 1
Dimensions (A X L X P) Mm: 48 x 96 x 103mm
Hole Gauge (A X L) Mm: 44,5 x 91,5 mm
Weight: ~ 0.5 kg
