Grossweight:80kg
Product Detail
Main features
* Comply with CCC,IEC EN,VED,BS,UL,JIS standard requiements.
* Latest international standard:500VA AC Hipot capacity(AC 5KV/100mA),short-circuit output current exceeds 200mA.Built-in optional leakage current test network MD card,meeting requirements of different industrial standards Maximum test current of Ground Bond resistance is up to 64A
*6 in 1:AC Hipot,Insulation Resistance,Ground Bond resistance,Leakage Current,Running Power,Low-Voltage Start.
Standby power consumption is optional for AN9651F(F)and AN9651S(F),minimum is low to 0.50w,accuracy is 0.2%
* Simple operation:LED backlit screen display.menu operation,Chiense/English langues,socket test fixture.
* Flexible configuration:Built in isolated transformer,AC frequency conversion power supply,frequency conversion power supply and industrial PC combiantion
* Satisfy lattest requirements:Follow the production line developing trends of comprehensive,fast,automation and information.Satisfy quality management,5s management and refid management requirements.
|
AC Hipot test |
|||
|
Booster rated output capacity |
500VA(5000V/100mA) |
||
|
Booster maximum short-circuit current |
>200mA |
||
|
Output waveform |
Sine wave, <3%(pure resistance,5000V/1mA),<3%(From empty load to full load) |
||
|
Output voltage setting |
Range |
500~5000V |
|
|
Resolution |
5V |
||
|
Accuracy |
±(3%×setting+10V) |
||
|
Frequency setting |
Range |
50Hz/60Hz |
|
|
Accuracy |
±0.1%×setting |
||
|
Alarming limits setting |
Current upper-limit |
0.10~99.99mA |
|
|
Current lower-limit |
0.00~10.00mA |
||
|
Compensation current setting |
Range |
0.00~10.00mA, automatic testing, compensation can be set to ON/OFF |
|
|
Time setting |
Range |
1~999s |
|
|
Ramp up time range |
1~100s |
||
|
Accuracy |
±(0.1%×setting+1count) |
||
|
Breakdown current alarm |
Range |
0.10~99.99mA |
|
|
Accuracy |
±(3%×reading+3counts) |
||
|
Insulation Resistance test |
|||
|
Rated output capacity |
2VA(1000V/2mA) |
||
|
Output voltage regulation |
<3%(From no load to full load) |
||
|
Output voltage ripple |
<1% |
||
|
Output voltage setting |
Range |
DC 500Vor1000V |
|
|
Accuracy |
±(3%×setting+3counts) |
||
|
Alarming limits setting |
Resistance upper-limit range |
0.0~99.9 MΩ,100~2000MΩ(If upper-limit is set to 0, it will not make adjudgment for upper limit) |
|
|
Resistance lower-limit range |
0.3~99.9 MΩ, 100~2000MΩ |
||
|
Time setting |
Range |
1~999s |
|
|
Accuracy |
±(0.1%×setting+1count) |
||
|
Insulation resistance measurement |
Range |
0.0~99.9 MΩ, 100~2000 MΩ |
|
|
Accuracy |
≤200MΩ: ±(3%×reading+3counts) |
||
|
>200MΩ:±(8%×reading+8counts) |
|||
|
Ground Bond Resistance test |
|||
|
No load output voltage |
<12v span=""> |
||
|
Output current setting |
Range |
3~30A |
|
|
Accuracy |
±(3%×setting+0.2A) |
||
|
Current range instruction |
Optional: 3 ~ 64A test current |
||
|
Current frequency setting |
Range |
Sine waveform 50Hz/60Hz |
|
|
Accuracy |
±0.1%×setting |
||
|
Test time setting |
Range |
1~999s |
|
|
Accuracy |
±(0.1%×setting+1count) |
||
|
Result display mode |
Ground resistance or voltage |
||
|
Ground resistance display mode |
|||
|
Alarming limits setting |
Resistance upper-limit range |
3A≤output current≤10A:10~600 mΩ |
|
|
Resistance lower-limit range |
0~100 mΩ |
||
|
Compensation resistance setting |
Range |
0~200 mΩ, automatic testing, compensation can be set to ON/OFF |
|
|
Ground bond resistance measurement |
Range |
10~600 mΩ |
|
|
Accuracy |
±(3%×reading+ |
||
