Measuring range: Max. 1,500 kg/m³
Accuracy in adjusted range: 0.5 kg/m³
Process temperature: -40°C to +125°C
CIP/SIP temperature and duration non-Ex version: 145 °C for max. 30 min
Ambient temperature: -40°C to +70°C
Process pressure absolute: Max. 50 bar
Material of the wetted parts: 1.4404
Communication: Can be combined with Pico 3000, Pico 3000 RC, mPDS 5, and Edge
Process connections: Adapter for inline, bypass, and tank installation
Flange: DIN/EN, ANSI, JIS, Tri-Clamp, VARIVENT® N, G 3/8”, Tube OD 12 mm, or 1/4”
U-tube inner diameter: 6.3 mm
Recommended flow rate: 100 L/h to 500 L/h
Degree of protection: IP 66 / 67 / NEMA 4X
Dimensions: Ex: 245 mm x 160 mm x 205 mm
Standard adjustment range: 600 kg/m³ to 1,200 kg/m³
Weight: 4.5 kg
