Measuring Range
Viscosity: 0.3 mm²/s to 5,000 mm²/s:
Density: -
Temperature: +15 °C to +100 °C (one temperature, second temperature optional):
Precision
Viscosity repeatability* and reproducibility*: 0.1 % and 0.35 %
Density repeatability* and reproducibility*: -
Temperature repeatability: 0.005 °C
Temperature reproducibility: 0.03 °C from +15 °C to +100 °C
Performance
Sample volume min. / typical: 1.5 mL / 5 mL
Solvent volume min. / typical: 1.5 mL / 6 mL
Max. sample throughput: 37 samples per hour
Data memory: 1,000 measurement results
HID (Human Interface Device): 7" touchscreen
Interfaces: 4 x USB (3 x A, 1 xB)
Power supply: At instrument: DC, 24 V /3A, AC adapter 90 VAC to 264 VAC, 47 Hat to 63 Hz, < 75W
Ambient conditions: 15 °C to 35 °C, max. 80 % r.h. non-condensing
Net weight in kg: 5.6 kg
Dimensions (W x D x H): 26.5 cm x 36.5 cm x 18 cm
*Attested at the points of works adjustment or calibration correction points, not including the uncertainty of the standard
