TECHNICAL CHARACTERISTICS
Dosing system
Dosing system: Vaccum pump (or peristaltic on request)
Sampling tube
Diameter : 12 mm
Longueur : 5 mètres en standard
Length : 5 meters (plus on request)
Material : PVC reinforced with clear ballast brass or stainless steel at the end of tube
Volume precision: 1 ± 1 ml
Detection system: Conductive fast response
Succion height: 6 meters
Speed volume: 0,5 m/s (to 5m height)
Sample volume: 20 – 200 ml
Claning of the sample: Yes
Clearing blow (before sampling): 1 to 120 seconds
Clearing blow (after sampling): 1 to 120 seconds
Blow pressure: 0,6 bars
Metering vessel: DURAN glass. No tools needed for mounting
Sample storage
Bidons: See datasheets
Controller
Remote start on external contact: YES
Sampling from external contact (eg flowmeter): 1 to 999 contacts
Starting late: 1 min to infinite
Sample Time: 1 min to 250 h
Intervals: 1 min to 100 h
Number of programs: 9 (simultaneous or chained)
Analog output: 0 or 4 to 20 mA
Interface: RS232 or RS485, RTC Modem (wired) or GSM Modem
Remote control: option
Batteries: Lead acid batteries
Autonomy: 600 samples
Norms: CE
Cabinet: Portable with handle
Material: Stainless steel AISI304 (1.4301)
Charger: Internal
Protection: IP 55
Operating temperature: 0 to 55 °C
Humidity: 80 % at 30 °C / 50% at 40 °C
Weight (with batteries): 13,5 kg
Dimensions H * W * D (mm): 430 * 415 * 290
For specific range please check the attachment below!
