Sensor principle: Frequency conversion ion flow
Measure range: 0～25.00% O2
Accuracy:
0.01～99.9 ppm: ±5ppm
100～999.9ppm: ±3%FS
1000～9999 ppm: ±3%FS
1.00%～25.00 %: ±3% of the measured value
Repeatability:
0.01～99.9 ppm ±2.5ppm
100～999.9ppm: ±1.5%FS
1000～9999 ppm: ±1.5%FS
1.00%～25.00 %: ±1.5% of the measured value
Stability:
0.01～99.9 ppm ±2.5ppm/7d
100～999.9ppm: ±1.5%FS/7d
1000～9999ppm: ±1.5%FS/7d
1.00%～25.00%: ±1.5% of the measured value /7d
Response time: T90＜20s (after full preheating)
Relay contact point capacity: 24VDC，0.2A
Power supply: 85～264VAC，50/60Hz
Communication: RS232(standard)/RS485(optional)
Environment
temperature: -10～50℃
Environment Humidity: <80%RH
Sample gas pressure: atmospheric conditions±10% (Gas outlet should be atmospheric conditions)
Analyzer size: L×W×H=264mm×190mm×159mm;
Floor installation size: L×W=210mm×195mm(Φ5 x 4 bolt hole)
Analyzer weight: about 3.7-4.1kg
