Port Size NPT: 1.00˝
Low Range* (Accuracy): —
Standard Range (Accuracy): 8.0 to 60.0 (±15.0%)
Wetted Materials Body: Brass
O-Ring: Viton®
Low Flow Adaptor: Glass Reinforced Polypropylene
Operating Pressure, Maximum: 200 PSIG (13.8 bar) @ 70°F (21°C), 100 PSI (6.9 bar) Max. @ 212°F (100°C)
Optional SS Face Plate 500 PSI
Operating Temperature: -20°F to 212°F (-29°C to 100°C)
Rotor Pin: Ceramic
Rotor: PPS Composite, Black
Lens: Polysulfone
Electronics: 150°F (65°C) Ambient
Viscosity, Maximum: 200 SSU
Input Power: 4.5 VDC to 24 VDC
Output Signal: 4.5 VDC to 24 VDC Pulse. (Sourcing)
Pulse Rate Dependent on Flow Rate, Port Size and Range.
Current Consumption: 8 mA, No Load
Current Source Output, Max.: 70 mA
Frequency Output Range: 15 Hz (Low Flow) to 225 Hz (High Flow)
Electrical Termination: 22 AWG PVC-Jacketed, 24˝ Cable. Color Coded: Red = +VDC; Black = Ground; White = Signal Output
