Range Basic Measurement Accuracy ; Test Current
20mΩ: ±(0.1% of reading + 0.03 % of range) ; 1A typical
200mΩ: ±(0.05% of reading + 0.03 % of range) ; 100mA typical
2Ω: ±(0.05% of reading + 0.03 % of range) ; 10mA typical
20Ω: ±(0.05% of reading + 0.03 % of range) ; 1mA typical
200Ω: ±(0.05% of reading + 0.02 % of range) ; 1mA typical
2kΩ: ±(0.05% of reading + 0.01 % of range) ; 1mA typical
20kΩ: ±(0.1% of reading + 0.01% of range) ; 100µA typical
200kΩ: ±(0.2% of reading + 0.01 % of range) ; 10µA typical
2MΩ: ±(0.3% of reading + 0.01 % of range) ; 1µA typical
Test Signal
Drive Mode: DC+, DC-,Pulsed+, Pulsed -, Pulsed ±, Stand by
Dry Circuit: Open Circuit Voltage less than 20mV; for 200mΩ, 2Ω, 20Ω ranges only
Measurement Time
Fast: 65ms
Medium: 150ms
Slow: 650ms
Temp. Correction / Conversion Function
Temp. Measurement Accuracy (Option)
-10.0˚C ~ 39.9˚C: ±(0.3% of reading+0.5˚C)
40.0˚C ~99.9˚C: ±(0.3% of reading+1.0˚C)
Temp. Sensor Type (Option): PT100/ PT500
Interface & I/O
Interface: RS-232(Standard) , GPIB, Handler (Optional)
Output Signal: Bin-sorting & Pass/Fail judge
Comparator: Upper/Lower limits in value
Bin Sorting: 8 bin limits in %, ABS
Trigger Delay: 0~9999ms
Trigger: Internal, Manual, External, BUS
Display: 240 x 64 dot-matrix LCD display
Correction Function: Zeroing
General
Operation Environment Temperature : 10˚C~40˚C,Humidity : < 90 % R.H.
Power Consumption: 80 VA max.
Power Requirement: 90 ~ 132Vac or 180 ~ 264Vac, 47 ~ 63Hz
Dimension (H x W x D): 100 x 320 x 346 mm / 3.94 x 12.6 x 13.62 inch
Weight: 4.2 kg / 9.25 lbs
