Output Phase: 1
Output Ratings:
Power: 3000VA
Voltage
Range/phase: 150V / 300V / Auto
Accuracy: 0.2% +0.2%of F.S.
Resolution: 0.1V
Distortion *1:
1% (15~45Hz)
0.5% (> 45~500Hz)
1% (> 500~1kHz)
2% (> 1K~2kHz)
Line Regulation: 0.1%
Load Regulation*2: 0.1%
Temp. Coefficient: 0.02% per˚C
Max. Current/Phase:
RMS: 30A/15A (150V / 300V)
Peak:
90A/45A (15~100Hz)
75A/38A (>100~1KHz)
60A/30A (>1K~2KHz)
Frequency
Range: 15 ~ 2kHz
Accuracy: 0.15%
Resolution:
0.01Hz (15 ~ 99.9Hz)
0.1Hz (100 ~ 999.9Hz)
0.2Hz (1k ~ 2kHz)
Input Ratings
Voltage
Operating Range: 1Ø 200~240V±10%VLN
Frequency Range: 47 ~ 63Hz
Current: 23A max.
Power Factor: 0.98 min.under full load
Measurement Voltage/Phase
Range: 0 ~ 150V / 0 ~ 300V
Accuracy (RMS): 0.25% + 0.1% F.S
Resolution: 0.1V
Current/Phase
Range (peak): 0 ~ 140A
Accuracy (RMS): 0.4% + 0.1%F.S.
Accuracy (peak): 0.4% + 0.2% F.S
Resolution: 0.01A
Power/Phase
Accuracy: 1% F.S. ( CF<6)
Resolution: 0.01W
Frequency
Range: 15 ~ 2kHz
Accuracy: 0.01% +2 count
Resolution: 0.01Hz
Others
Efficiency: 80% typical
Temperature
Operating: 0 ~ 40˚C
Storage: -40 ~ +85˚C
