Working Voltage: AC 208~240V, Single Phase
Pressure Vessel
Made of Ni-Based Super-alloy ( Waspaloy or equivalent )
Air cold flange via aluminium heat radiator
Reactor Capacity & Dimensions:
70mm OD x 35mm ID x 326 mm height
300 mL capacity
Working Temperature & Controller:
RT-1100°C Max.
Digital temperature controller with 30 segment programmable
Temperature accuracy +/- 1°C
Working Pressure:
18 MPa, ≤ 800 °C
13 MPa, ≤ 900 °C
8 MPa, ≤ 1000 °C
3 MPa, ≤ 1100 °C
Accessories: SS316 needle valve with 1/4 pipe connector & Pressure gauge included
Two consumable Copper Gasket(63mm O.D) are included
Dimension: 340 mm W x 320 mm D x 820 mm H
