Measuring Geometry: d/8°
Sphere Diameter: 54 mm (2.5 inches)
Light Source: Pulsed Xenon
Spectral Range: 400-700 nm
Effective Bandwidth: 10 nm
Reflectance Range: 0-200%
Spectrophotometer Principle: Concave holographic grating
Observer: 2° Standard Observer, 10° Standard Observer
Detector: Dual 256 element diode array
Color Repeatability: <0.03 CIELab dE* max on white ceramic tile
Color IIA: 0.15 CIELab dE*avg of 12 BCRA tiles;0.25 CIELab dE* max on any BCRA tile
Measurement Time: 2 sec (Gloss off & Image capture off)
Measurement Interval: 3.67 sec (Gloss on & Image capture on with 2 flashes)
UV Setting: 100% / 0% / Adjusted (Instantaneous numerical adjustment of UV with no mechanical filter); 400 nm UV cutoff filter
UV Calibration Support: CIE Whiteness / Ganz-Griesser
Apertures: Dual Apertures
Illuminated / measured: LAV/SAV
LAV: 15mm / 11mm: LAV/USAV
SAV: 10mm / 6.5mm: SAV/USAV
USAV: 6.5mm / 2.5mm:
Battery Type: Rechargeable Li-Ion Battery (Removable)
Battery Performance: 2000+ Dual Flash Measurements
Sample Placement: Camera (Live View Alignment)
Interface: USB-C / Bluetooth® / Wi-Fi
Operating Environment: 5º to 40ºC up to 85% RH, non-condensing
Screen Display: 4” TFT LCD 480×800 Pixels Display with Touchscreen
Display Resolution: 480 x 800
Weight: 0.81 Kg (1.8 lbs)
Dimensions: 229 x 89 x 81 mm (L x W x H)
Color Evaluations: CIELabCh, CIELab, CIELCh, XYZ, Whiteness CIE, Whiteness E313, Yellowness E313, Reflectance, Measurement Parameters, CMC, CIE94, CIE2000, Hunterlab, 555 Sort Code, Metamerism DIN, Metamerism CIE, Whiteness Stensby, Whiteness Berger, Whiteness Hunter, Strength, Contrast Ratio, ISO/AATCC Fastness, ISO/AATCC Staining, FMC II, PQS II, PQS II GEE9F6, LRV Equation, Optical Density*
Illuminants: A, C, D65, D50, D55, D75, F02, F07, F11, TL83, TL84, U3000, Horizon, U3500, LEDT8G, LED-B1, LED-B2, LED-B3, LED-B4, LED-B5, LED-BH1, LED-RGB1, LED-V1, LED-V2
Result Display Items: Colorimetric Values / Pass-Fail Judgment / Color Difference Plot / Reflectance Curve / Captured Image
Data Storage: 1000 standards, 5000 batches
Languages: English, French, German, Spanish, Italian, Simplified Chinese, Korean, Portuguese, Polish
Export Data Format: QTX, CSV, CXF, Excel
Datacolor Software Compatibility: Tools, Match Station, Match Textiles, Match Pigment, Paint, Colibri
