Work plate dimension (WxD): φ135mm (5 inch)
Work plate material: stainless steel cover with ceramic
Motor type: Brushless DC motor
Stirring positions: 1
Max. stirring quantity (H2O): 20L
Max. magnetic bar (length): 80mm
Speed range: 100~1500rpm; resolution: ±1rpm
Speed display: LCD
Temperature display: LCD
Heating temperature range: Room temp.~340°C, increment: 1°C
Temperature control accuracy: ±1°C (<100°C); ±1% (>100°C)
Over temperature protection: 420°C
Temperature display accuracy: ±0.1°C
External temperature sensor: PT1000 (accuracy: ±0.2)
"Hot" warning: 50°C
Data connector: RS232
Protection class: IP42
Motor rating input: 18W
Motor rating output: 10W
Power: 550W
Heating output: 500W
Voltage: 100~120/200~240V; 50/60Hz
Dimension (WxDxH): 160×280×85mm
Weight: 2.8kg
Permissible ambient temperature and humidity: 5~40°C, 80%RH
Please choose the EURO plug when ordering:
+ Euro plug, 200V~240V/50Hz/60Hz
Optional accessories (refer to datasheet page 72-73)
