Work plate Dimension (WxD): φ135mm (5 inch)
Work plate material: stainless steel cover with ceramic
Motor type: Brushless DC motor
Stirring positions: 1
Max. stirring quantity (H2O): 3L
Max. magnetic bar (length): 50mm
Speed range: 200~1500rpm
Resolution: ±1rpm
Speed display: LED
Temperature display: LED
Heating temperature range: Room Temp.~280°C, increment: 1°C
Temperature control accuracy: ±1°C (<100°C); ±1% (>100°C)
Overheating protection: 320°C
Temperature display accuracy: ±1°C
External temperature sensor: PT1000 (accuracy: ±0.5°C)
"Hot" warning: 50°C
Protection class: IP21
Motor rating input: 5W
Motor rating output: 3W
Power: 515W
Heating output: 500W
Voltage: 100~120/200~240V; 50/60Hz
Dimension (WxDxH): 150×260×100 mm
Weight: 1.8kg
Permissible ambient temperature and humidity: 5~40°C, 80%RH
Please choose the EURO plug when ordering:
+ Euro plug, 200V~240V/50Hz/60Hz
Optional Accessories (refer to datasheet page 72-73)
