Dimensions: 48mm x 130mm x 44mm Width x Height x Depth
Weight: 220-250g
Ambient Conditions:
Temperature: -20 to +50ºC
Pressure: 700 to 1300 mbar
Relative Humidity: 10 to 95% r.h
Protection Class: IP67
Alarms:
Visual: 360º
Audible: Multi-tone > 90dB at 30cm
Vibration
Operating Times:
> 12 hours with alkaline and NiMH
> 13 hours with NiMH HC
> 250 hours without Ex sensor with alkaline batteries
Charging Time: < 4 hours
Datalogger: Retrievable using an infrared interface > 1000 hours with 4 gases at a recording interval of 1 value per minute
Sensor Specifications
Gas/ Range/ Resolution:
Combustible/ 0-100% LEL/ 1% LEL
Carbon Monoxide (CO)/ 0-2,000 ppm/ 2 ppm
Hydrogen Sulfide-LC (H2S)/ 0-100 ppm/ 0.1 ppm
Oxygen (O2)/ 0-25 Vol %/ 0.1% Vol
Nitrogen Dioxide (NO2)/ 0-50 ppm/ 0.1 ppm
Sulfur Dioxide (SO2)/ 0-100 ppm/ 0.1 ppm
