Mains power supply
• Connection according to IEC/EN60320-1; C320
• Mains supply: 90 V – 264 V AC
• Frequency: 50 / 60 Hz
• Power consumption:
@ 230 V AC (5010 VA)
@ 115 V AC (3510 VA)
• Fuse: type F (20 A / 250 V )
Output data
• Test current ranges (from 0 to Imax) and maximum load capacity at 25°C (77°F) ambient temperature:
Current: 800 A
Max.load capacity: 300 ms
• Full Load Voltages at maximum current
@ 230 V AC (4.70 V)
@ 115 V AC (2.85 V)
Measurement
• Resistance range: 0 – 499.9 mΩ
*Expandable up to 6 Ω
• Resolution:
0 – 999.9 µΩ; 0.1 µΩ
1.000 mΩ – 9.999 mΩ; 1 µΩ
10.00 mΩ – 99.99 mΩ; 10 µΩ
100.0 mΩ – 999.9 mΩ; 0.1 mΩ
Resolution on optional ranges:
(0 – 99.99 µΩ/ 0.01 µΩ)*
(1.000 Ω – 6.000 Ω/ 1 mΩ)**
• Typical accuracy ± (0.1 % rdg + 0.1 % FS)
Display
• LCD screen 20 characters by 4 lines
• LCD display with backlight, visible in bright sunlight.
Interface
• RMO-G is equipped with an USB port
• optional: RS232
• optional: Bluetooth communication interface
Test Result Storage
• RMO-G can store up to 500 measurements
Printer (optional)
• Thermal printer
• Paper width 58 mm / 2.3 in
Dimensions and weight
• Weight: 11.5 kg/25.4 lbs
• Dimension (W x H x D) mm / in: 480 x 190 x 385 mm (18.9 x 7.48 x 15.16 in)
