- System
+ Relative humidity: 10–95%
+ Weight (complete system): 7.3 kg [16 lbs]
+ Carrying case WxHxD: 500x415x170 mm [19.7”x16.3”x6.7”]
- Measuring units: M / S
+ Type of detector: True PSD 30 mm [1.2”]
+ Resolution: 0.001 mm [0.05 mils]
+ Measuring errors: ±1% +1 digit
+ Measurement range: Up to 10 m [33 feet]
+ Type of laser: Diode laser
+ Laser wavelength: 635–670 nm
+ Laser class Safety: class II
+ Laser output: <1 mw="" br=""> + Electronic inclinometer 0.1° resolution
+ Thermal sensors: -20–60 °C
+ Environmental protection: IP class 65
+ Temperature range: -10–50 °C
+ Housing material Anodized aluminium / ABS plastics
+ Dimensions WxHxD: 60x67x42 mm [2.36”x2.63”x1.65”]
+ Weight 164 g [5.8 oz]
- Display unit
+ Type of display/size: VGA 5.7” colour screen, backlit LED
+ Displayed resolution: 0.001 mm / 0.05 thou
+ Internal battery (fixed): Heavy duty Li Ion chargeable
+ Operating time: Approx. 30 hours (at typical user cycle)
+ Temperature range: -10–50 °C
+ Connections USB A, USB B, Easy-Laser® units, Charger
+ Wireless communication Class I Bluetooth® wireless technology
+ Internal memory: >100 000 measurements can be saved
+ Help functions Calculator, Unit converter
+ Environmental protection IP class 65
+ Housing material PC/ABS + TPE
+ Dimensions WxHxD: 250x175x63 mm [9.8”x6.9”x2.5”]
+ Weight 1020 g [2.3 lbs]
- Barcode reader
+ Connection USB A
+ Stickers 25 pcs. barcode stickers included
- Cables
+ System cables Length 2 m [78.7”], with Push/Pull connectors.
+ USB cable Length 1.8 m [70.8”]
- Brackets etc.
+ Shaft brackets Type: V-fixture for chain, width 18 mm [0.7”].
Shaft diameters: 20–450 mm [0.8”–17.7”]
Material: anodised aluminium
+ Rods Length: 120 mm, 60 mm [4.72”, 2.36”] (extendable)
Material: Stainless steel
- EasyLink™ Data base software
+ System requirements Windows® XP, Vista, 7. For the export functions, Excel
2003 or newer must be installed on the PC.
A complete system contains
1 Measuring unit M
1 Measuring unit S
1 Display unit
1 Barcode reader incl. stickers
2 Cables 2 m [78.7”]
2 Shaft brackets with chains
2 Extension chains
4 Rods 120 mm [4.72”]
4 Rods 60 mm [2.36”]
1 Measuring tape 3 m [9.8’]
1 USB memory with EasyLink™ PC software
1 USB cable
1 Charger (100–240 V AC)
1 Shoulder strap for display unit
1 Quick reference manual
1 CD with documentation
1 Carrying case
