Hardness Scale: HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1
Conversion Scale: HRA, HRB, HRC, HBS, HBW, HRD, HRF, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HK
Test force:
1. gf: 10, 25, 50, 100, 200, 300, 500, 1000
2. N: 0.098, 0.245, 0.49, 0.98, 1.96, 2.94, 4.9, 9.8
Operation:
1.Focus: Manual focus
2.Loading: Automatic loading - dwell - unloading test force
3. Turret: Automatic turret
Magnification: 10X Digital eyepiece; 10X, 40X Objective lens Total magnification: 100X (observation), 400X (measuring)
Indenter: Standard Micro Vickers diamond indenter 136°±0.5°
Dwell time: 1-99s (unit: 1 second)
Data display: 5.6 inch digital touch screen
Data storage: Yes, turn-off machine memory will automatic save
Data output: Built-in printer
X-Y table: Size: 100x100mm; Max. Move range: 25x25mm
Light source: Halogen lamp (image more real and clear, light source strength is adjustable )
Test space: 85x115mm (HxD)
Weight: Net weight: 52kg; Gross weight: 61kg
Size: Machine size: 490*185*515mm; Packing size: 630*430*860mm (LxWxH)
Delivery Packing List:
Machine host 1 pc
Screwdriver 1 pc
Weights 6 pc
Allen wrenches 1 set
Weights rod 1 pc
Horizontal adjusting screw 4 pcs
X-Y test table 1 pc
Power cable 1 pc
Thin specimen fixture 1 pc
10X digital eyepiece 1 pc
Flat mouth fixture 1 pc
Standard HV hardness block 2 pcs
Drill head fixture 1 pc
Fuse 1 pc
Gradienter 1 pc
Dust proof 1 pc
Quality certificate 1 pc
Manual book 1 pc
