Hardness Scale: HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1
Conversion Scale: HRA, HRB, HRC, HBS, HBW, HRD, HRF, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HK
Test force:
1. gf: 10, 25, 50, 100, 200, 300, 500, 1000
2. N: 0.098, 0.245, 0.49, 0.98, 1.96, 2.94, 4.9, 9.8
Operation:
1. Focus: Manual focus
2. Loading: Automatic loading - dwell - unloading test force
3. Turret: Automatic turret
Magnification: 10X Digital eyepiece; 10X, 40X Objective lens Total magnification: 100X (observation), 400X (measuring)
Indenter: Standard Micro Vickers diamond indenter 136°±0.5°
Dwell time: 1-99s (unit: 1 second)
Data display: 4.3 inch digital touch screen
Data storage: Yes, turn-off machine memory will automatic save
Data output: Built-in printer; U-flash (USB interface); Software auto generate test report on PC
X-Y table: Size: 100x100mm; Max. Move range: 25x25mm
Light source: Halogen lamp (image more real and clear, light source strength is adjustable )
Test space: 85x115mm (HxD)
Weight: Net weight: 52kg; Gross weight: 68kg
Size: Machine size: 490*185*515mm; Packing size: 625*420*900mm (LxWxH)
