Calibration: Points: ZERO/50/100/250/500/1000um
Units: um, mil
Minimum curvature radius convex: 1.5mm
Minimum curvature radius concave: 25mm
Minimum measuring area: Diameter 6mm
Power: One 9V battery
Operation Environment: Temperature:0~40℃(32~104℉) Humidity: 20%~90%RH
Size: 130mm x 62mm x 32mm (4.88” x 2.44” x 1.26”)
Weight: 100g(3.53oz)
Probe F
Principle: Magnetic Induction
Range: 0~1300um 0~51.2mil
Accuracy: ±(3%+2um) ±(3%+0.08mil)
Resolution: 0.1um/0.01mil
Minimum thickness of substrate: 0.5mm(0.02”)
Probe N
Principle: Eddy Current
Range: 0~1300um 0~51.2mil
Accuracy: ±(3%+2um) ±(3%+0.08mil)
Resolution: 0.1um/0.01mil
minimum thickness of substrate: 0.3mm(0.012”)
