Rockwell scale:HRE, HRL, HRM
Preliminary test force:10Kg (98.07N)
Total test force:60Kg (588.4N), 100Kg (980.7N), 150Kg (1471N) Tolerance range:±1.0%
Indenter:Ф3.175mmBall Indenter, Ф6.35mmBall Indenter, Ф12.7mmBall Indenter
Test force change:By change weights
Resolution:0.5HR
Hardness data read:Analog
Loading method:Driven by motor, button start
Test force duration:Fixed, 0-60 seconds
Test space:Maximum height :175mm Maximum throat depth:165mm
Size / weight:Instrument size: 520×215×700mm（L×W×H）/Net Weight: 78kg
Executive standard:ISO 6508，ASTM E-18，JIS Z2245，GB/T 230.
Packing List:
Instrument Main Body1 set
Ф3.175mmBall Indenter1 pc
Ф6.35mmBall Indenter1 pc
Ф12.7mmBall Indenter1 pc
Middle Plane Test Table1 pc
Large Plane Test Table1 pc
V-shaped Test Table1 pc
Hardness Block 75~85 HRE1 pc
Hardness Block 110~120 HRL1 pc
Hardness Block 100~110 HRM1 pc
Hardness Block 115~125 HRR1 pc
Weight A, B, C3 pcs
Power Cable1 pc
Fuse 2A2 pcs
Level1 pc
Horizontal Regulating Screw
4 pcs
Screw Driver1 pc
Spanner1 pc
Anti-dust Cover1 pc
Usage Instruction Manual1 copy
