Material measuring: Aluminium, steel, stainless steel, cast iron, plexiglass, PVC, polystyrene and polyurethane.
Tough, impact, waterproof and dust resistant equivalent to IP54
Measurement Mode: Pulsed-Echo (P-E), Echo-Echo ThruPaint™ (E-E) measurement Mode
Measurement Rate: 4Hz
Thickness Range: P-E: 0.63-500mm, E-E: 2.54 - 25.40mm
Measurement Accuracy: ±1% or ±0.1mm
Measurement Units: mm or inch
Selectable Reading Resolution: Lo; ie 0.1mm, 0.01 Inch, 10m/s, or 0.001 in/μs
Data Output: USB; to PC
Transducer Probe Type: Dual element
Battery Type: 2xAA
Battery Life: Alkaline: 15 hour, Lithium: 28 hour
Operating Temperature: -10 to 50°C
Size (w x h x d): 145x73x37mm
Weight (including batteries): 210
Packing List: Elcometer MTG4, 5MHz 1/4 right angle transducer, couplant, wrist harness, screen protector, protective case, 2 x AA batteries, calibration certificate, operating instructions
Note: A transducer is not suppied with the Gause, must be ordered separately
