Power Supply: 9V DC 6F22×1 PCS alkaline dry battery
LCD Size: 50.8mm×37mm
DC Voltage: Range: 400mV/4V/40V/400V/1000V | ±(0.8%+2)
AC Voltage: Range:400mV/4V/40V/400V/700V | ±(1.2%+5)
DC Current Range: 40A/400A/1000A | ±(2%+5)
AC Current: Range: 4A/40A/400A/1000A | ±(2%+10)
Resistance: Range: 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ | ±(1%+3)
Capacitance: Range: 10nF/100nF/1uF/10uF/100uF/1000uF/10mF | ±(3%+20)
Frequency: Range: 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz/40MHz | ± (0.5%+3)
Temperature: Range: -50°C～1000°C | ±(1%+4)
Automatic Range: √
Manual Range: √
AC Conversion Type: True effective value(TRMS)
Input Protection: √
Automatic Shutdown: About 10 minutes, can be set to no automatic shutdown
Diode Test: Can measure the LED work voltage below 3V
Duty Ratio Measurement: √
NCV (Live line) Measurement: √
Short Circuit Buzzer: √
Low Voltage lndicator: √
Input Impedance: About 10MΩ
Data Hold: √
Surge Signal Measurement: √
Clamp Jaw Size: Can measure max wire diameter Ф52mm
Meter Size: 249mm×89mm×38mm
Weight: About 360g (include battery); total weight: about 0.6kg (include accessory)
Working Temperature: 0℃～40℃ relative humidity <75%
Store Temperature: -10℃～ 50℃ relative humidity <80%
