Moving Area X / Y / Z: 430 / 400 / 100mm (Per Single Valve Calculation)
Vision System: 12-Megapixel Color Camera
Repeatability: +/- 0.01 mm/ axis
I/O Signals: 16 Inputs / 16 Outputs
Conveyor Type: Chain Drive
Adjustable Conveyor Width: 50~500mm
Conveyor Height: 890~940mm
Conveyor Speed: 150mm/sec
Communication Interface: SMEMA
Rotary Coating System-Type: Needle 2 (Right Side)
Rotary Coating System-Rotation Axis(V): ±40°
Working Humidity: 20~90% no condensation
Number of Spray / Dispense Valves: Multi-Axis Rotary Coating System / Dual-Valve System / Triple-Valve System
Moving Speed X&Y / Z: Max. 500 / 250 mm/sec
Data Storage Method: Industrial PC
Drive System/ Stepping Motor: XY Axis Servo Motors / Z Axis Micro Stepping Motor
Conveyor Width Adjustment: Motorized Width Adjustment / Programmable Control
PCB Edge Clearance: ≥6mm
Maximum Load Capacity: 5KG
Conveying Direction: From Left to Right
Power Supply: AC 200~240V
Rotary Coating System-Rotation Axis(R): 0~90°
Working Temp.: 10~40 °C
Dimensions WxDxH: 838*1090*1606mm (Excluding Additional Parts)
