Moving Area X/Y/Z (mm): 480 / 480/100 mm
Moving Speed X&Y/Z (mm/sec): XY/Z: 600/600 mm/sec
Data Memory Capacity: 9999 points/prog. 100 programs
Display Mode: Human-machine interface
Electric Screwdriver: Brushless DC voltage
Nozzle Specification: <9mm (maximum diameter)
Screw Feeder System: disc type M1.0~M3.0mm (1.0/1.2/1.4/1.7/2.0/2.3/2.6/3.0)
Working Temp.: 10-40°C
Machine Size WxDxH: 940 x 752 x 868 mm
Working Area X/Y (mm): 450 / 480 mm
Repeatability: +/- 0.01 mm/ Axis
Data Storage Method: USB/SD card
Teaching Mode: Touch screen human-machine interface
Input Power: 100V~230V / 450W
Screw Length: <18mm (maximum diameter)
Working Pressure: 5~7 kg/cm² dry air source
Working Humidity: 20-85% no condensation
Machine Weight: 68 kg
