TECHNICAL SPECIFICATIONS
Mainframe: Quad-core processor / 8 GB RAM
Operating system: Windows 10 IoT Enterprise LTSC 2021
Display: Touchscreen, color, 1280 × 800 TFT 203 mm (8 in)
Interfaces: RJ45 LAN 10/100/1000 Mbit/s; USB 2.0 ports (2); USB 3.0 port (1); Micro SD card slot; 3.5 mm headset/microphone port
Storage (internal flash memory): 128 GB
Battery Rechargeable: Li-ion smart battery (Two batteries with the high-power dual carrier)
Power supply: AC/DC adapter, input: 100 – 240 V; 50/60 Hz; 2.5 A max, output: 24 V; 3.75 A
With high-power dual carrier: AC/DC adapter, input: 100 – 240 V; 50/60 Hz; 5.0 A max, output: 24 V; 13.75 A
GENERAL SPECIFICATIONS
Size (H × W × D)
+ With single-depth module back / With single carrier: 210 mm × 254 mm × 66 mm (8 ¼ in × 10 in × 2 ⅝ in)
+ With double-depth module back / With dual carrier: 210 mm × 254 mm × 96 mm (8 ¼ in × 10 in × 3 ⅞ in)
+ With high-power dual carrier: 210 mm × 254 mm × 122 mm (8 ¼ in × 10 in × 4 ¾ in)
Weight (with battery):1.5 kg (3.3 lb)
+ With single carrier: 2.0 kg (4.3 lb)
+ With dual carrier: 2.4 kg (5.2 lb)
+ With high-power dual carrier: 3.2 kg (7.1 lb)
Temperature
+ Operating: 0 °C to 50 °C (32 °F to 122 °F)
+ Storage: –40 °C to 70 °C (–40 °F to 158 °F) b
Relative humidity: 0 % to 95 % non-condensing
