Output Current: 2A
Output Voltage: 15V
Output Power: 30W
Channels: 8CH
CC mode:
Range: -2A～2A
Design resolution: 0.05mA
Design accuracy (25±3℃): 0.02%+1mA
Readback resolution: 0.1mA
Readback accuracy (25±3℃): 0.02%+1mA
Temperature coefficient: ＜25ppm/℃(25±3℃)
CV mode:
Range: 0～15V
Design resolution: 0.3mV
Design accuracy (25±3℃): 0.01%+1mV.
Readback resolution: 0.1mV
Readback accuracy (25±3℃): 0.01%+1mV.
Temperature coefficient: ＜25ppm/℃(25±3℃)
Voltage ripple (20Hz～20MHz): 2mVrms
Current ripple (20Hz～20MHz): 2mArms
Voltage rise time (no load): ＜500μs (time for 10%～90% change)
Voltage rise time (full load): ＜500μs (time for 10%～90% change)
Voltage fall time (no load): ＜500μs (time for 10%～90% change)
Voltage fall time (full load): ＜500μs (time for 10%～90% change)
Transient response: ＜50μs
Withstand voltage (output): 1500VDC
Withstand voltage (channels): 1500VDC
Programming response: ＜5ms
Communication: LAN/RS485
Input AC Voltage: 220VAC±10%
Input AC Current: ＜1A
Size: 88.1 * 482.6 * 650 mm (Height*Width*Depth)
Weight: 18Kg
