Accuracy Specifications:
Accuracy is specified for a period of one year after calibration, at 18 °C to 28 °C (64 °F to 82 °F), with relative humidity to 80 %. Accuracy specifications are given as: ±([% of reading] + [number of least significant digits]). Accuracy specification assumes ambient temperature stable ±1 °C.
Battery Internal Resistance[1]:
Range Resolution Accuracy
3 mΩ0.001 m1 % + 8
30 mΩ0.01 mΩ0.8 % + 6
300 mΩ 0.1 mΩ0.8 % + 6
3000 mΩ1 mΩ0.8 % + 6
V dc:
Range Resolution Accuracy
6 V 0.001 V0.09 % +5
60 V 0.01 V0.09 % +5
600 V 0.1 V0.09 % +5
[1] The measurement is based on ac injection method. The injected source signal is <100 mA, 1 kHz
Records Capacity :
Battery Internal Resistance: Saved by test sequence with time stamp, up to 999 records
Battery: Voltage Display and save with battery internal resistance, up to 999 records
V dc: Up to 999 records
