- mA (clamp):
+ 0 to 20.99 mA /0.2% + 2 counts
+ 21.0mA to 100.0 mA /1% + 5 counts
mA (series with test jacks)
+ 0 to 24.00 mA /0.2% + 2 counts
- mA source (Maximum mA Drive:24 mA into 1,000 ohms)
+ 0 to 24.00 mA /0.2% + 2 counts
- mA simulate (Maximum voltage 50 V dc)
+ 0 to 24.00 mA /0.2% + 2 counts
- Voltage source (2 mA maximum drive current)
+ 0 to 10.00 V dc /0.2% + 2counts
- Voltatge Mesaure
+ 0 to 30.00 V dc /0.2% + 2counts
Diameter conductor: 0.177” or 4.5 mm max
IP Rating:IP 40
Size:59 x 38 x 212 mm, (2.32 x 1.5 x 8.35 in.)
Weight 260G, (9.1 oz.)
Included: Soft Carrying Case, Users Manual
