Display: English Touch Screen LCD
Measuring range: Capacitance: 5pF-200pF
Relative permittivity: 1.000-30.000
Dielectric loss factor: 0.00001-100
DC Resistivity: 2.5MΩm- 20TΩm
Measurement accuracy: Capacitance: ±0.5% + 1pF
Relative permittivity: ±1% reading
Dielectric loss factor ± (1% reading + 0.0001)
DC resistivity: ±10% reading
Resolution: Capacitance: 0.01pF
Relative permittivity: 0.001
Dielectric loss factor: 0.00001
Temperature range: 0-125 ° C
Temperature measurement error: ±0.5 °C
AC experimental voltage: 0-2200V,continuously adjustable, frequency: 50Hz
DC test voltage: 0-600V, continuously adjustable
Power consumption: 100W
Power supply voltage: AC 220V ± 10%
Power frequency Ambient temperature: 50Hz/60Hz ±1%, 0-40 °C
Relative humidity: <80%
Dimensions: 420mm × 380mm × 385mm
Weight: About 21 kg (free cup)
