Test current: auto, <20mA, 40mA, 200mA, 1A, 5A, 10A
Measuring range: 0.5mΩ～0.8Ω (10A)
1mΩ-4Ω (5 A)
5mΩ-20Ω (1 A)
100mΩ-100Ω (200mA)
1Ω-500Ω (40mA)
Accuracy：±(0.2%+2words)
100Ω-100KΩ (<20mA), Accuracy：±(0.5%+2words)
Minimum resolution: 0.1μΩ
display: 7 Inch Touch color LCD, resistance display, significant number is 4
data storage: 1000 groups
Work environment: Ambient temperature: 0℃～40℃,
Relative humidity: <90%RH,
no condensation
Power supply: AC 220V±10V, 50Hz±1Hz (fuse 2A)
Maximum power consumption: 200W
Dimensions: 360*290*170(mm)
Weight: host：6.7kg, line box：5kg
