Rated Voltage: 250V, 500V, 1000V, 2500V, 5000V, 10kV, 15kV
Output Voltage Accuracy: (5%~10%) ±10V
Insulation Resistance Range: 15KV, 30TΩ, 7mA
Output Short Circuit Current: ≥7mA
Power Supply: Rechargeable lithium battery pack 6.2Ah
Polarization Index Test: Yes
Dielectric Absorption Ratio Test: Yes
Ramp Test Mode: The output voltage will start at 10% of the preset voltage and increase in steps of 10% until the preset voltage is reached
Filtered Resistance Test Mode: 10S, 20S, 30S, 40S (4 selections)
Voltage Test: Range: AC/DC 0V~1000V;Accuracy: ±(5%+3V)
Current Test: Range: 0.01nA~9mA;Accuracy: ±(5%+0.2nA);
Capacitance Test: Range: 10nF~25uF;Accuracy: ±(10%+nF)
Voltage Monitor: Monitor the voltage of the measured object, and monitor discharge status after test, Forbidden to test when voltage is larger than 36V, protect instrument and operator.
Test Timer: Automatic record test time, time range: 0s~9999s
Storage Function: Automatically store the real-time test data with test date, time and timing, total of 1000 groups
Upload Function: Upload the stored data to computer with USB communication cable.
Battery Power Indication: Yes, when battery voltage low will remind to replace the battery
Automatic Shutdown: After 15 minutes start up will shut down automatically without any operation
Meter Dimension: 280mm × 260mm × 160mm
Meter Weight: 4900g (include battery)
Test Wire: Red high voltage test wire 1 pcs (with alligator clip 1PCS and hook 1PCS), green test wire 1PCS, black test wire 1PCS
Protection Level: Close the case IP65; open the case IP40
Working Environment: -20℃~50℃; 80%rh
Store Environment: -25℃~65℃; 80%rh
Insulation Resistance: 50MΩ (1000v) (between the test circuit and shell)
Withstand Voltage: AC 3kV 50Hz 1min (between the test circuit and shell)
Suitable Safety Standard: IEC61010-1,IEC61326-1
