AC Input voltage range: 85VAC to 256VAC, 47 – 63 Hz
Power Factor: FL 0.99 NL 0.98
Output Polarity: +ve or –ve (Please specify when ordering)
Maximum Voltage: 50kV
Maximum Current: 2.4mA
Polarity: P or N
Model Number: 8050P (+ve) or 8050N (-ve)
Voltage Load Regulation: 0.01% of full voltage for a no load to a full load change
Voltage Line Regulation: +/- 0.005% of full voltage over the specified input voltage range
Current Load Regulation: 0.01% from 0V to full voltage
Current Line Regulation: +/- 0.01% of full current over the specified input voltage range per 8 hours after
Voltage Ripple: 0.1% p-p of output voltage
Current Stability: 0.02% per 8hrs after ½hr warm up
Temperature Coefficient: 100 ppm per ˚C
Temperature Operating: 0˚C to 45˚C
Storage: -20˚C to +85˚C
Interlock: Open Interlock will shut down unit
Circuit Protection: Overvoltage, Overcurrent, Arcing and Over temperature
Relative Humidity: Non condensing
Weight: Model specific, approximately 3Kgs
Dimensions: 95.25mm (H) x 127mm (W) x 279.4mm (D)
Power Input Connector: IEC320 with mating connector x 2 Metres
HV Output Connector: Proprietary HV Connector
Control Interface Connector: 15 pin ‘D’ connector (Male)
