ELECTRICAL PARAMETERS
Accuracy class:
0.05%, 0.1%
Power supply: Single phase AC 85-265V, 50/60 Hz
AC voltage output
Range: 57.7V / 100 V / 220V / 380V, Switch automatically
(max 500V)
Adjustment resolution: 0.01%, 0.1%, 1%, 10%,
Accuracy: 0.05% RG
Stability: Better than 0.01% RG/1min
Distortion degree: Better than 0.1% (not capacitive load)
Load capacity: 40VA
Full load regulation rate: Less than 0.01% RG
Full load regulation time: Less than 1ms
Temperature drift: 8 PPM/°C
Long-term stability: 60 PPM/year
AC current output
Range: 0.1A / 0.25A / 0.5A / 1A / 5A / 10A / 20A / 50A /
100A, switch automatically
Adjustment resolution: 0.01%, 0.1%, 1%, 10%,
Accuracy: 0.05% RG
Stability: Better than 0.01% RG/1min
Distortion degree: Better than 0.1% (not capacitive load)
Load capacity: 40VA
Full load regulation rate: Less than 0.01% RG
Full load regulation time: Less than 1mS
Temperature drift: 8 PPM/°C
Long-term stability: 60 PPM/year
Power output
Active power accuracy: 0.05% or 0.1%
Reactive power accuracy: 0.1% or 0.2%
Stability: Better than 0.01% RG/1min
Phase
Range: 0°-359.99°
Adjustment resolution: 0.01°, 0.1°, 1°, 10°
Accuracy: 0.03°
Frequency
Range: 40-65 Hz
Adjustment resolution: 0.001 Hz, 0.01 Hz, 0.1 Hz, 1Hz
Accuracy: 0.002 Hz
Temperature drift: 0.5 PPM/°C
Long-term stability: 4 PPM/year
Harmonic
Harmonic times: 2nd-63th
Adjustment resolution: 0.1% (Compared with fundamental wave)
Harmonic content (Compared with fundamental wave)
Voltage: ≤40%
Current: ≤40%
Phase: 0°-360°
MECHANICAL PARAMETERS
Dimensions (W×D×H) (mm): 420x320x155
Weight (kg): 12
ENVIRONMENTAL CONDITIONS
Operating temperature: 0°C ~ 40°C
Storage conditions: -30°C ~ 60°C
Relative humidity: ≤85%
